Features
Flexible:
Available to order in panels, bundles, or kits
Simple Management and Scalability:
Scale up to 21 panels
Multiple Verification Methods:
RFID, Bluetooth, QR Code, Fingerprint
Atlas Panels
Atlas Series access control panels make it simple to secure your facility – whether you’re protecting a single entry point or managing an entire building.
Choose from 1, 2, or 4-door configurations, and scale up to 84 doors as your needs grow. Setup is straightforward: the built-in web interface means no software installation, and flexible connectivity options like Power over Ethernet (PoE) and WiFi keep installation costs low.
Atlas panels work with virtually any reader or credential technology you already have, and are available as standalone panels, bundles, or ready-to-install kits.
Atlas Panels
Atlas Series access control panels make it simple to secure your facility – whether you’re protecting a single entry point or managing an entire building.
Choose from 1, 2, or 4-door configurations, and scale up to 84 doors as your needs grow. Setup is straightforward: the built-in web interface means no software installation, and flexible connectivity options like Power over Ethernet (PoE) and WiFi keep installation costs low.
Atlas panels work with virtually any reader or credential technology you already have, and are available as standalone panels, bundles, or ready-to-install kits.
Specification
| Specification | Details |
|---|---|
| Capacity | 5,000 (Fingerprint and/or card users), 10,000 transactions plus unlimited archive downloads |
| Browsers Supported | Chrome, Firefox, Edge, Safari |
| Types of Readers Supported | ZKTeco KR Series readers, FR1500-A-ID, 3rd party 125kHz & 13.56MHz readers, Wiegand, OSDP, RS-485 readers, Other upon request |
| Communication | TCP/IP, Wiegand, OSDP |
| Number of Inputs | 5 (2 Exit Button, 2 Door Sensor, 1 Aux) |
| Number of Outputs | 3 (2 Form C relay for lock and 1 Form C relay for Aux output) |
| Weight | 10 lbs (4kg) |
| Recommended Power | 12V DC, 3A (PoE) |
| Dimensions | 14in. X 2.5in. X 12in, 380mm(L) X 80mm(W) x 280mm(H) |
Integrations
Video Integrations
Visitor Management Integrations :
Power & Scalability
Built for Modern Infrastructure & Power Flexibility
Atlas panels aren’t just powerful—they are designed to fit seamlessly into your existing workflow. For large-scale deployments and centralized power management, Atlas is fully compatible with:
Altronix Trove™: Easily integrate Atlas boards into Altronix’s modular access and power integration enclosures.
LifeSafety Power™: Utilize ProWire™ unified power systems for a clean, pre-wired, and professional head-end.
DIN Rail Mounting: Every panel supports standard DIN rail installation, ensuring a tidy and organized cabinet even in the most complex 84-door systems.
